Our fire alarm control panels are designed for small to medium scale facilities to meet your different needs and use whether for your home, shop, commercial buildings, office, apartment or restaurant. We guarantee that our alarm control panels, that are UL, ULC and FM approved, are the ideal solution for your security, safety and fire alarm system.
Maple Armor supplies reliable, intelligent and addressable remote annunciators with or without LCD display.
Maple Armor’s Manual Stations feature a robust enclosure and are made of durable materials. Its rounded corners will give a more modern look to your installation.
Maple Armor offers a wide range of fire alarm signaling devices that are easy to install and configure.
Our addressable detectors feature a slim design that allows them to be integrated into any building. Maple Armor’s heat and smoke detectors respond quickly and efficiently everytime.
Maple Armor provides you with a wide range of easy to use fire alarm modules such as: Single Input, Dual Input, Relay, Conventional Zone, Loop Isolator, In-Suite Isolator, Synchronization, etc.
We understand that emergency lights play an important role in fire safety. Working closely with Rayonled Lighting Systems, Maple Armor offers a wide range of different emergency lights and exit signs to provide a one-stop shop for our customers to meet all their fire alarm and emergency light needs.
We supply a great variety of components that enhance the performance of you fire alarm systems.
FireWatcher 327 ALU – ADDRESSABLE LOOP UNIT
One ALU can support one addressable loop circuit, which supports up to 252 points of addressable devices. It can initialize and operate all devices residing on the loop and it communicates all relevant devices and event information, such as alarms and troubles, to the Central Processing Unit (CPU). No limitation between device types.
FireWatcher 337
NOU – NOTIFICATION OUTPUT UNIT One NOU can support two independent notification appliance circuits with synchronization. The circuit topology supports Class A or Class B wiring. The maximum current is 2A per NAC. Multiple notification code types available.
FireWatcher 347
ROU – RELAY OUTPUT UNIT
One ROU card can support five dry contact relays: Alarm Relay, Supervisory Relay, Trouble Relay, Other Signal Relay, and Programmable Relay. The Relay contacts are in the C Form Style. The address is set by the rotary switch on the board. Valid address is 1. It meets the UL864 10th Edition Listed standard and the ULC-S527 3rd Edition Listed standard.
FireWatcher 357
XNU – EXTERNAL NETWORK UNIT
The FW357A provides both Class X and Class B wiring to communicate with panels and annunciators in Network to form a fire network system. It meets the UL864 10th Edition and the ULC-S527 3rd Edition standards. It can support up to 109 panels or remote annunciators.
Portable Programmable Device
FireWatcher 412
PORTABLE PROGRAMMABLE DEVICE
The portable programmable device FW412 unit allows the user to read addresses of the existing devices and can program the addresses of new devices.
Remote LED Indicator
FireWatcher 561-RI
REMOTE LED INDICATOR
The FW561-RI (without test switch) and FW561-RI-L (with test switch) Remote LED indicators are components that provide visual indication of the device status connected with it.
End-of-Line Resistor Plate
FireWatcher 422
END-OF-LINE RESISTOR PLATE
The FW422, EOL Resistor Plate effortlessly supports the Class B supervision to its connected devices. With an elegant finish, it features clearly displayed identification pictograms. The RFL has a 10K Ohm resistor, which is compatible with all Maple Armor monitoring and notification circuits.
